D Tech 3600 ampli

Mã sản phẩm: D Tech 3600 ampli

Nhà sản xuất: TAFN
Tình trạng: Còn hàng

Hotline hỗ trợ 24/7: 0903831080

Giá : 0 đ

Đặt hàng ngay

2 ohm Dual (Per ch.) 1750W RMS*

2.66 ohm Dual (per.ch) 2200W RMS**

4 ohm Dual (Per ch.) 1650W RMS

8 ohm Dual (Per ch.) 850W RMS

4 ohm Bridge - Mono 3500W RMS*

8 ohm Bridge - Mono 3300W RMS

16 ohm Bridge - Mono 1700W RMS

D-TECH 3600 is a highly reliable advanced digital power amplifier capable of delivering high power consistently. it is long proven as an amplifier of choice in a wide range of high-power applications. Very small in size and is highly efficient. Reproduces sound with outstanding clarity and stability like never before possible with analog amplifiers.

Unmatched power in a 1U chassis

High damping factor even when clipping

  Very stable output at any load
  Short circuit-able speaker outputs
  Top-of-range Neutrik connectors
  Highly portable, light weight

Very high AC voltage tolerance range

Specifications:

Sensitivity for full rated power	1.4 Volts RMS or 0.775 Volts
Frequency Response 20 Hz to 20 KHz	1dB at any power level
Signal to Noise ratio 20 Hz to 20 KHz	More than 103 dB
Total Harmonic Distortion (THD)	0.1%
Intermodulation Distortion (IMD)	0.05%
Damping Factor	800 From 20 Hz to 400 Hz.
Load Impedance	Safe with all types of loads
Output power stereo mode at 8 ohm (stereo)	950 + 950 Watts RMS (both channels driven)
Output power stereo mode at 4 ohm (stereo)	1800 + 1800 Watts RMS (both channels driven)
Output power stereo mode at 2.66 ohm (stereo)	2300 + 2300 Watts RMS (both channels driven)
Output power stereo mode at 2 ohm (stereo)	2000 + 2000 Watts RMS (current limited by AGC)
Output power bridged mode at 16 ohm (mono)	1900 Watts RMS
Output power bridged mode at 8 ohm (mono)	3600 Watts RMS
Output power bridged mode at 4 ohm (mono)	4000 Watts RMS (current limited by AGC)
Overload and short-circuit protection system	Current limited controlled by AGC at 45A per CH.
Overheat protection system	Cut-off at internal 85 Deg. Resume at 45 Deg.
Power Supply protection	Soft start - Against all severe voltage fluctuations
AC Input Voltage without affecting max. Output Power	190 V - 260 Volts AC. (when loading 4 ohms)
AC Input Voltage at moderate power operation	140 V - 260 Volts AC. (when loading 4 ohms)
Dimensions W x D x H	480 x 460 x 44 mm (1U. 19" Rack mount )
Weight	9.50 Kg.
